Shell And Tube Heat Exchanger

Shell And Tube Heat Exchanger Our Company are engaged in offering excellent quality Shell And Tube Heat Exchanger to our valuable clients The Shell and Tube U-tube are the most common type of heat exchanger used in the process petroleum chemical and HVAC industries it contains a number of parallel U tubes inside a shell Shell Tube heat exchangers are used when a process requires large amounts of fluid to be heated or cooled Due to their design shell tube heat exchangers offer a large heat transfer area and provide high heat transfer efficiency ATE Shell and Tube He/Sheat Exchangers are designed to meet various process requiremensts.

Shell and Tube heat exchangers can provide steady heat transfer by utilizing multiple passes of one or both fluids ATE shell and tube heat exchangers come in two 2 and four 4 pass models standard and multi-pass custom models Shell and Tube heat exchangers use baffles on the shell-side fluid to accomplarehed mixing or turbulence Design Code IS-4503 IS-2825 AMSE SEC VIII TEMA Type Fixed Tube Sheet Removable tube Bundle U-Tube Coil in Tank double Pipe CapacityRange As per client s requirement

Shell Diameter 2 quot to 125 quot Tube Length 2 to 40 Tubes Plain Finned or U-Tube M O C Tubes Carbon Steel Stainless Steel Copper Adm Brass Aluminium Titanium Tantalum Hastolloy Alluminium Bronze monel Duplex Cupronickle M O C Shell Carbon Steel Stainless Steel Copper Monel Brass Aluminium.

Product Details:
